Your current location：Home > Products > UNDERSIDE SANDER
This machine can be connected with the traditional sander to produce, can sand top and bottom surface in one pass, saving time and high working efficiency.
Equipped with press beam, effectively solve the problem of biting head and sweeping end of workpiece.
Siemens Automatic CNC Control System, equipped with Siemens low- voltage electrical parts, safe and reliable.
| 技術參數 | Technical Specification | SUR- R- R1300 | SUR- R- P1300 | SUR- R1300 |
|---|---|---|---|---|
| 最大加工寬度 | Max working width | 1300mm | 1300mm | 1300mm |
| 最短加工長度 | Min working length | 350mm | 350mm | 350mm |
| 加工厚度 | Working thinkness | 10-100mm | 10-100mm | 10-100mm |
| 輸送速度（變頻調速） | Feeding speed | 5-30m/min | 5-30m/min | 5-30m/min |
| 砂帶尺寸 | Abrasave belt size | 1330×2200mm | 1330×2200mm | 1330×2200mm |
| 總功率 | Total Moter power | 93.625KW | 93.625KW | 71.6KW |
| 工作壓力 | Working air pressure | 0.6Mpa | 0.6Mpa | 0.6Mpa |
| 壓縮空氣消耗量 | Air consumption | 17m3 /h | 17m3 /h | 17m3 /h |
| 吸塵量 | Volume of dust collection device | 13700m 3 /h | 13700m 3 /h | 9500m 3/h |
| 外形尺寸 | Overall dimensions | 2164×3020×2282mm | 2164×3020×2282mm | 2164×2530×2282mm |
| 重量 | Net weight | 7500kg | 7500kg | 5950kg |
